The 2D/3D drawing workspace brings mechanical drafting and solid modeling into one CAD environment. VariCAD includes tools for assemblies, part libraries, surface development, and engineering calculations.
Model mechanical parts and assemblies
Create three-dimensional mechanical components, then arrange parts into assemblies. VariCAD also includes mechanical part libraries for designs that use standard components. Surface development tools support work with surfaces, while parameter options let users define model parameters as part of a design workflow.
The same application supports 2D drawing alongside 3D modeling. This lets a project include a solid model and its related drafting work without switching to a separate CAD program.
Draft drawings and export CAD files
Use the 2D drafting tools for technical drawings, then export in formats suited to other CAD and manufacturing workflows. VariCAD supports these export formats:
- 3D models: STEP, STL, and IGES
- 2D drawings: DWG and DXF
Calculate and get started with built-in guidance
VariCAD includes calculation tools for 3D objects and 2D sections. These provide a way to evaluate model geometry and drawing sections within the CAD workflow.
The program offers built-in hints, and its startup guidance recommends video tutorials for learning the tools. With many specialized commands available, the hints can provide direction while getting familiar with the workspace.
Pros
- Combines 2D drafting with 3D solid modeling
- Supports assembly design and mechanical part libraries
- Exports 3D models to STEP, STL, and IGES
- Exports 2D drawings to DWG and DXF
System requirements: Windows 10, Windows 11 · 64-bit only · At least 2GHz processor · 4GB RAM · Graphics card with hardware support for OpenGL 4 · 3- or 5-button mouse with scroll wheel
What is VariCAD used for?
It is a mechanical CAD program for creating 2D drawings, 3D models, and assemblies, with tools for calculations and surface development.
Which CAD formats can VariCAD export?
It exports 3D models as STEP, STL, and IGES files, and 2D drawings as DWG and DXF files.
Can VariCAD handle both 2D drafting and 3D modeling?
Yes. It includes 2D drafting and 3D solid modeling in the same application.
